Overview
Place of Origin: |
Guangzhou, China |
Brand Name: |
HOSTON |
Model Number: |
XY120CCY060 |
Certification: |
CE |
Minimum Order Quantity: |
1 |
Packaging Details: |
Standard Exporting Packing. OEM brand can be printed/pasted. |
Delivery Time: |
15-40 days,depend on specific model and quantity |
Payment Terms: |
*For order less than US$ 10K, full payment before production. *30% T/T Payment before production, 70% T/T Payment before shipment. |
Description
High environmental adaptability:Unique and exquisite appearance style, suitable for outdoor places;
High compatibility: supports CCS2,CHAdeMO;
Intelligent energy management:reduces operation and maintenance costs;
High waterproof rating:IP54 waterproof rating, with multiple protection functions such as overheating and leakage;
Flexible adaptation:Covering different powers, optional adjustment, flexible expansion and adaptation;
LCD screen:7 "LCD touch screen, providing users with a better operating experience;
Applications
Suitable for all types of electric vehicles in the market, including electric vehicles, electric trucks, electric buses, electric yachts, electric forklifts, etc;
Specifications
|
Rated power |
60kW |
|
Input Wiring |
Three-phase 3P+N+PE |
|
AC Input Rated Voltage |
400V ± 10% |
|
AC Maximum Input Current |
95A |
|
AC Frequency |
50Hz |
|
Operating Temperature |
‘-30℃～＋50℃(power reduces above 50℃) |
|
Operating Humidity |
5%-95% without condensation |
|
Altitude during operation |
≤ 2000M |
|
Internal Cooling Method |
Forced air-cooling |
|
Efficiency |
≥ 95% (above half load) |
|
Harmonics |
iTHD ≤ 5% (above half load) |
|
Power factor |
≥0.99 |
|
Voltage Accuracy |
≤ ± 0.5% |
|
Current Accuracy |
≤ ± 1% |
|
Vehicle Connectors |
2 x CCS 2 |
|
DC Output Voltage Range |
200-1000V |
|
Constant power interval voltage |
300-1000V |
|
DC Output Current Range |
0~200A |
|
Display |
7-inch LCD touch screen |
|
LED Indicators |
Tri-colour LEDs |
|
Emergency Stop Button |
Included |
|
Access Modes |
RFID Card, QR code scanning via APP, Credit Card(optional) |
|
Network Interface |
3G/4G/Ethernet |
|
Communication Protocol |
OCPP 1.6-J ,OCPP 2.0.1 (Can Be Upgraded Later) |
|
Remote Upgrade |
YES |
|
Dimensions (W x D x H) |
730 mm x 560mm x 1700mm |
|
Weight (kg) |
347kG |
|
Connector Cable Length |
The standard is 5m, and 5-10m(optional) |
|
Degree of protection |
IP55 |
|
Mechanical Impact |
IK10 |
|
Pollution degree (PD) |
PD3 |
|
Noise (lab environment) |
≤65dB |
|
Protection function |
Overvoltage, Undervoltage, Short circuit, Overcurrent, |
|
Standards |
EN 61851-1:2019; EN IEC 61851-21-2:2021; EN 61851-23:2014; EN 61851-24:2014; DIN 70121 / ISO 15118; |
|
Certifications |
CE |
|
Warranty |
24Months with Warranty Extensions Available |
